NRS Cat Fish Cataraft Frame

Item: 92060.04
  • Image for NRS Cat Fish Cataraft Frame
  • Alternate product image 92060_02_Right_013015
  • Alternate product image 92060_02_Front_013015

What Size do you need?
In Stock & Ready to Ship!

Your order ships for free!*

Product Details

NRS Catarafts deliver performance, agility and stability, whether transporting passengers and gear or sport boating, and fishing is no exception. Catarafts make great fishing platforms, and the NRS Cat Fish is the ideal frame to put anglers in position to hook the big ones.
  • NRS frame systems are the easiest frame systems on the market to customize. This completely adjustable and adaptable cataraft frame lets you rearrange the pieces to suit your needs.
  • The raised Angler Seat Bar, with High-Back Swivel Seat, elevates the fisherman for the best sight lines and casting angles.
  • The 66" frame width gives your cat the narrower profile that can make all the difference in rocky, congested waters.
  • The 72" frame width offers a wide, stable fishing platform and extra internal width for coolers, dry boxes and gear.
  • There is 31" between the lower side rails on the 66" wide frame, and 37" on the 72" wide frame.
  • The 120" frame length provides plenty of room for adding coolers, dry boxes and overnight gear, or extra anglers.
  • Customize your Cat Fish Frame with Aluminum and mesh Cargo Floors, Cataraft Anchor System, Thigh Hooks, Stripping Baskets and Side Rail Racks.
  • Hot-forged aluminum alloy LoPro™ Fittings are the heart of the NRS frame system, and allow complete adjustability for all frame parts.
  • NRS 8" Oar Mounts are also constructed with hot-forged aluminum alloy resulting in a lighter, sleeker and stronger Oar Mount, and a nylon insert reduces rowing friction.
  • Create your seat bars for the padded Drain-Hole Seats by U-bolting a Universal Seat Mount to a cross bar or the Angler Seat Bar. This allows you to precisely set the location of the seat and the seat angle.
  • Frame includes: four Side Rails, two Yokes, Foot Bar, Universal Seat Mount, Cross Bar, Angler Seat Bar with Universal Seat Mount, High-Back Drain-Hole Seat, High-Back Swivel Seat and a pair of 8" Oar Mounts.


Product Tips

NRS Cataraft Yokes place the center of the lower side rails 11 1/8" below the center of the top side rail. Generally they work best on NRS River Cats, Kodiak Cats and other manufacturer's cat tubes 24" or larger in diameter. Measure the depth of your inside D-rings to see if this is your best choice. For cats with smaller diameter tubes, the Sport Cat Frame (# 92072.04) is an excellent choice.

  • Cataraft Frames
  • Fishing Frames
Weight: 66" W is 91 lbs.
Included Components:
  • 4 - Side Rails
  • 2 - Yokes
  • 1 - Foot Bar
  • 1 - Cross Bar
  • 2 - Universal Seat Mounts
  • 1 - Angler Seat Bar
  • 1 - High-back Drain Hole Seat
  • 1 - High-Back Swivel Seat
  • 1 - Pair of 8" Oar Mounts
Suggested minimum amount of straps used to secure the frame. (Sold Separately): 4 (3' straps), 4 (4' straps) and 8 (2' straps)

Product Instructions

  1. Lay out the frame parts as shown in the image above. Place the yokes upside down with the narrow end up.
  2. Attach the Universal Seat Mounts to the center of the cross bar and raised seat bar.
  3. Install the U-bolts on the inner yoke LoPro fittings. Add the washers and the nuts, leaving them loose. Slide the two inner side rails in through the U-bolts, then tighten the nuts.
  4. Turn the yoke right side up so that the inner rails are supporting the frame. Follow step 2 with the outer rails.
  5. Set the seat, foot and cross bars in place and add the U-bolts. If any of the bars need to be repositioned it may be necessary to remove the U-bolts to make adjustments.
  6. Add seats and oar mounts.
  7. Check to be sure that all of the U-bolts are tight. Periodically check the tightness of all nuts and seat bolts.
